DSA 500X4
DSA 500X4 Amplifier
The Danley DSA series is a collection of multi-purpose installation amplifiers. The DSA500x4 is a two-space rack mount DSP amplifier with four channels rated at 500 watts per channel making it ideal for large-scale sound systems or venues. The amplifier has a built in Wireless Access Point (WAP) for simple connection and configuration via WiFi.
Product Specifications
Channels
4 x Lo-Z / 2x Hi-Z
Output power @ 2 Ohms
4 x 500 W (SE)
Output power @ 4 Ohms
4 x 500 W (SE)
2 x 1000 W (BTL)
2 x 1000 W (BTL)
Output power @ 8 Ohms
4 x 250 W (SE)
2 x 1000 W (BTL)
2 x 1000 W (BTL)
Output power @ 70V
2 x 1000 W (BTL)
Output power @ 100V
2 x 1000 W (BTL)
Total System Power
2000 W
Power Consumption
700W
Weight
16.31 lbs | 7.4 kg
Dimensions
88 x 440 x 332 mm | 3.5 x 17.3 x 13.1 in
Output Circuitry
UMAC(TM) Class D – full bandwidth PWM modulator with ultra-low distortion
Output Voltage
65 Vp / 130 Vpp
(SE unloaded)
130 Vp / 260 Vpp
(BTL unloaded)
(SE unloaded)
130 Vp / 260 Vpp
(BTL unloaded)
THD+N (typical)
< 0.05% (+0/-0.25dB (8 Ohm load, 3dB below rated power)
Frequency Response
20Hz – 20kHz (+0/-0.25dB (8 Ohm load, 3dB below rated power)
Protection Circuits
Short circuit-, DC-, Undervoltage-, Temperature- and Overload protection
Operating Temperature
0-40C
Accessories
2x rack ears, 4 x adhesive feet
Power Ratings
1% THD @ 120Vac and 230Vac
