This loudspeaker combines the incredible power of a Tapped Horn™ wrapped around the high fidelity and pinpoint pattern control of an SM-100. Thanks to its tight, low-end response, one loudspeaker per venue side (with or without subwoofers) will do an amazing job of covering a substantial seating area. It is truly an amazing one box solution.

Product Specifications

coverage Pattern
110 Conical
operating frequency range
50Hz-17 kHz +/-3 dB
30Hz-24 kHz +/-10 dB
continuous output
124 dB SPL
peak output
130 dB SPL
98 dB SPL (2.83 Volts into rated Z, at 1 meter) measured in free space
magnitude response
45 Hz-18kHz
driver complement
Low 4 x 8″
High 1 x 8″ coaxial
33.5 X 20.5 X 19 inches
135 Lbs
Rated Impedance
4 Ohms
Power Rating
800 Watts Cont.
3200 Watts Peak
Related Products

Brackets & Protective Covers

In addition to the SM family of products, Danley offers a number of accessories for the SM100B.
