DNA 3K8C

DNA 3K8C Amplifier

Like all of our products, this amplifier will provide you with the best methods of delivering quality, crystal clear sound to your audience.

Features include:

  • Eight channels of sonically pure Class D amplification
  • Eight analog inputs
  • Unique, precise, 96kHz digital signal processing
  • Over‐designed switch mode power supply 85V to 240V Auto-sensing PSU
  • 3,000 watts RMS total output
  • Ethernet network for system operation and monitoring
  • Analog, AES3 and optional DanteTM digital network audio
  • Powerful grouping & multi‐layer EQ
  • Manufactured in the UK

RATED POWER PER CHANNEL

2 Ohms
400W
4 Ohms
400W
8 Ohms
400W
4 or 8 Ohms Bridged
800W
25V line operation
400W
70V line operation
400W
100V line operation
355W

POWER SUPPLY

Switch mode power supply
Switch mode power supply
Mains inrush current (max for <10ms)
6A at 115V, 12A at 230V
Connector Type
L6-20

DIGITAL SIGNAL PROCESSING

Physical inputs to DSP drive modules
8x analog, 2x AES & 8x DanteTM inputs can be routed to four DSP drive modules
Drive module input processing
Input signal routing, delay, gain, HPF, Phase, Mute EQ: 2x low shelf, 6x PEQ / band pass and FIR shelving filters
Drive module output processing
Source, delay, gain, Phase, Mute, crossover filters, VX limiters EQ: low shelf, 8x PEQ / band pass and shelving filters
Preset management
10 snapshots for device wide setup, 50 presets for loudspeaker settings Presets can be recalled to sets of outputs or individual outputs as required
Overlays
Twelve additional independent overlays of EQ, Delay and Gain Flexible grouping for effective control of many amplifier channels in large systems
Hardman crossover filters
Better out of band rejection than Linkwitz-Riley
