60 ˚ compact mid –high box



The SM60M is a mid-high version of the SM60F without the dual 8” low frequency drivers. The SM60M is designed for use with a subwoofer and works very well with the THmini. Available in install version only.

Product Specifications

Coverage Pattern
60˚ horizontal
60˚ vertical
Operating Frequency Range
270 Hz – 15 kHz +/- 3dB
178 Hz – 24 kHz – 10dB
Continuous Output
124 dB SPL
Peak Output
130 dB SPL
100 dB SPL
(2.83 Volts into
rated Z, at 1 meter)
measured in free space
Magnitude Response
270 Hz- 15 kHz
Driver Complement
1 x 5″ Coaxial
20.6 x 20.6 x 16.3 inches
45 lbs
Rated Impedance
8 Ohms
Power Rating
250 Watts Continuous
1000 Watts Peak
Danley Products

SM Family of Products

Danley’s SM family of loudspeakers is simply a smaller, lighter version of our Synergy Horn family. What that means is that SM loudspeakers deliver the same clarity and full range of audio thanks to our proprietary single source technology.
