The highest directivity loudspeaker on the market
SH25
SH25
The SH25 is ideal where you need great fidelity, high output and pattern control in both the horizontal and vertical axes. A single SH25 has a frequency response of 90 Hz -18kHz. Combining four in a array will extend the low frequency performance down to 50 Hz. The SH25 features a driver compliment of eight 6.5″ woofers, four 4″ drivers, and one 1″ high compression driver. With the two recessed handles, the SH25 is also easy to maneuver.
Product Specifications
Coverage Pattern
25˚ horizontal
25˚ vertical
25˚ vertical
Operating Frequency Range
90 Hz -18 kHz +/- 3 dB
70 Hz – 20 kHz – 10 dB
70 Hz – 20 kHz – 10 dB
Continuous Output
137 dB SPL
Peak Output
143 dB SPL
Sensitivity
110 dB SPL
(2.83 Volts into rated Z, at 1 meter)
(2.83 Volts into rated Z, at 1 meter)
Magnitude Response
90Hz-18kHz
Driver Complement
Low 8 x 6.5″
Mid 4 x 4″
High 1 x 1″
Mid 4 x 4″
High 1 x 1″
Dimensions
28 x 28 x 50.7 inches
Weight
176 lbs
Rated Impedance
4 Ohms
Power Rating
1000 Watts Continuous
4000 Watts Peak
4000 Watts Peak
